| Power handling RMS / Max. | P |
100 / 200 Watts |
| Impedance | Z | 4 Ω |
| DC resistance | Re | 3.1 Ω |
| Frequency response | 40 Hz – 4,000 Hz | |
| Resonance frequency | Fs | 57 Hz |
| Mechanical Q factor | Qms | 5.35 |
| Electrical Q factor | Qes | 0.63 |
| Total Q factor | Qts | 0.57 |
| Compliance | Cms | 440 µm/N |
| Equivalent air volume | Vas | 10.8 L |
| Force factor | B*I | 6.1 Tm |
| Sensitivity | SPL | 91 dB @ 2.83 V / 1m 88 dB @ 1W / 1m |
| Cone area | Sd | 133 cm² |
| Moving mass | Mms | 17.9 g |
| Cone material | Mica-Paper composite cone | |
| Mechanical resistance | Rms | 1.19 kg/s |
| Voice coil diameter | ø | 25 mm |
| Voice coil winding height | 12 mm | |
| Max. linear excursion | Xmax | +/- 3 mm |
| Outer diameter | ø | 166 mm / 6.54″ |
| Installation diameter | ø | 141 mm / 5.55″ |
| Installation depth | 66.5 mm / 2.62″ |
| Izmērs | 6.5" |
|---|---|
| Zīmols | HELIX |
