SounDigital 800.5 EVO 6 – 4 Ohm

Power @ 4Ω: 4 x 100W RMS
Power @ 8Ω: 4 x 66W RMS
SUBWOOFER: 4Ω: 1 x 400W

Bridge Power @ 8Ω: 2 X 200W RMS
SUBWOOFER: 8Ω: N/A

Frequency Response (-3dB): 80Hz ~ 25kHz
SUBWOOFER: 5Hz ~ 80Hz
Low Pass Filter (12dB/octave): 80Hz
High Pass Filter (12dB/octave): 80Hz
Operating Voltage: 9V ~ 16V
SNR: 103.88dB
SUBWOOFER: 102dB
Input Sensitivity (RCA): 0.2V ~ 2V
Current Draw (music): 39A
Current Draw (max.): 78.7A
Total Efficiency: 80%
Damping Factor (@100Hz nominal impedance): 200
Power Cable: 10mm² (7 AWG)
Speaker Cable: 1.5mm² (15 AWG) / 2.5mm² (13 AWG)
Recommended Fuse (music): 40A
Recommended Battery (minimum): 60Ah
Width: 6.01″ / 15,7 cm
Lenght: 4.52″ / 11,7 cm
Height: 2.07″ / 5,5 cm
Weight: 0.74 kg / 1.63 lb
