| Power handling RMS / Max. | P |
200 / 400 Watts |
| Impedance | Z | 2 x 2 Ω |
| DC resistance | Re | 3.6 Ω |
| Frequency response | 25 Hz – 500 Hz | |
| Resonance frequency | Fs | 55 Hz |
| Mechanical Q factor | Qms | 8.31 |
| Electrical Q factor | Qes | 0.88 |
| Total Q factor | Qts | 0.80 |
| Compliance | Cms | 256 µm/N |
| Equivalent air volume | Vas | 13.5 L |
| Force factor | B*I | 6.7 Tm |
| Sensitivity | SPL | 90 dB @ 2.83 V / 1m 87 dB @ 1W / 1m |
| Cone area | Sd | 194 cm² |
| Moving mass | Mms | 32 g |
| Cone material | Injected polypropylene | |
| Mechanical resistance | Rms | 1.39 kg/s |
| Voice coil diameter | ø | 38 mm |
| Voice coil winding height | 20 mm | |
| Max. linear excursion | Xmax | +/- 7.5 mm |
| Outer diameter | ø | 195 mm / 7.68″ |
| Installation diameter | ø | 173.5 mm / 6.83″ |
| Installation depth | 47.0 mm / 1.85″ | |
| Features | FlexMount200 |
| Izmērs | 8" |
|---|---|
| Zīmols | HELIX |
