SounDigital 1200.1-4 EVOPS Marine

1200.1 EVOPS – 4 OHMS

Power @ 1Ω: N/A
Power @ 2Ω: N/A
Power @ 4Ω: 1 x 1200 WRMS

Operating Voltage:

8V – 16V

Current Draw (Music):

45,3A

Current Draw (Max):

90,6A

Recommended Fuse (Music):

60A

Total Efficiency:

92%

Damping Factor:

> 2000

Frequency Response (-3dB):

5Hz – 25kHz

SNR:

90dB

Crossover:

50Hz – 500Hz

Subsonic:

5Hz – 25Hz

Bass Boost:

50 Hz fix – 0 to +12dB

Width:

5.3 in / 13,6 cm

Length:

7 in / 18 cm

Height:

2.2 in / 5,5 cm
