| Output power RMS | |
| – @ 4 Ohms | 8 x 55 Watts |
| – @ 2 Ohms | 8 x 70 Watts |
| – @ 1 Ohm | – |
| – bridged @ 4 Ohms | – |
| – bridged @ 2 Ohms | – |
| – Subwoofer output @ 4 Ohms | – |
| – Subwoofer output @ 2 Ohms | – |
| Amplifier technology | Class HD |
| Inputs | 6 x Highlevel speaker input 1 x Optical SPDIF (12 – 96 kHz) 1 x MEC 1 x Remote In |
| Input sensitivity | Highlevel 5 – 11 Volts |
| Input impedance RCA / Cinch | – |
| Input impedance highlevel | 9 – 33 Ohms with ADEP.3 |
| Outputs | 8 x Speaker output 2 x RCA / Cinch (mono) 2 x Remote Out |
| Output voltage RCA / Cinch | 3 Volts RMS |
| Frequency response | 20 Hz – 22,000 Hz |
| DSP resolution | 64 Bit |
| DSP power | 295 MHz (1.2 billion MAC operations/second) |
| Sampling rate | 48 kHz |
| DSP type | Audio signal processor |
| Signal converters | A/D: BurrBrown D/A: BurrBrown |
| Signal-to-noise ratio digital input | 105 dB (A-weighted) |
| Signal-to-noise ratio analog input | 103 dB (A-weighted) |
| Distortion (THD) | < 0.015 % |
| Damping factor | > 100 |
| Operating voltage | 10.5 – 18 Volts (max. 5 sec.down to 6 Volts) |
| Power rating | DC 12 V ⎓ 40 A max. |
| Idle current | 685 mA |
| Max. remote output current | 500 mA |
| Operating temperature range | -40° C to +70° C |
| Fuse | 2 x 25 A LP-Mini-fuse (APS) |
| Additional features | Class HD technology with dynamically controlled power supply, 32 Bit CoProcessor, ADEP.3 circuit, Smart Control Port, Start-Stop capability, USB, MEC slot, Auto Remote switch, galvanically isolated Line Outs |
| Dimensions (H x W x D) | 44 x 185 x 164 mm / 1.73 x 7.28 x 6.46“ |
| Kanālu skaits | 8 |
|---|---|
| Zīmols | Match |
